SEASON 2025
BRAKES Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
CASSETTE Shimano Cues CS-LG400, 11-50T
CHAIN KMC eGlide
CRANKSET ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
DERAILLEUR REAR Shimano Cues RD-U6000-GS, 11-Speed
FORK SR Suntour XCR34 2CR Air, Tapered, 15x110mm, 140mm
FRAME Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
GRIP ACID Hybrid Perform
HANDLEBAR CUBE Rise Trail Bar 35
HANDLEBAR STEM CUBE Performance Stem E-MTB 35, FPI-Link
HEADSET ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
HUBS F: CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt | R: CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt
PEDALS ACID PP MTB
RIM CUBE EX30, 32H, Disc, Tubeless Ready
SADDLE ACID Venec Lite
SEAT POST CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
SHIFTERS Shimano Cues SL-U6000, Rapidfire Plus
SHOCK SR Suntour EdgeX R 205x60mm (27.5: 185x55mm), Rebound Adjust, Trunnion Mount
TYRES Schwalbe Nobby Nic, Performance, 2.6
WEIGHT 26.4 kg
FEATURES
Durable aluminum frame construction
Bosch Performance Line CX motor
SR Suntour 140mm travel fork
Magura MT Thirty 4-piston brakes
Shimano 11-speed drivetrain
MOTOR/DRIVE UNIT Bosch Drive Unit Performance Line CX, Smart System 25KPH
MOTOR BRAND Bosch
MOTOR MODEL Performance Line CX
MOTOR POWER (WATTS) 250
MOTOR TORQUE (NM) 85
BATTERY Bosch PowerTube 800
BATTERY BRAND Bosch
BATTERY MODEL PowerTube 800
BATTERY SIZE (WATT-HOURS) 800
EBIKE DRIVE SYSTEM Mid Drive
